Equipments

CarMaker (IPG Automotve)

  • Rapid virtual prototyping
  • Realistic 3D visualization
  • Flexible scalability
  • Data analysis and evaluation

MicroAutobox 3 (dSPACE)

  • Control Algorithm Validation Tool
  • Sample rate: Analog In9-200kS/s,
  • Analog in17-333kS/s, Analog in8-Max 1MS/s
  • Power consumption: 100W
  • Resolution: 16bits

CANOE (Vector)

  • FPGA Based CAN Signal Test Equipment
  • CAN I/O : 4ch(CAN-FD)
  • D-SUB9 socket

DEWE R8 (Dewetron)

  • High Speed Data Acquisition System
  • 32x Analog ports, 8x CAN and 8x Digital ports
  • Mil STD

DEWE A13 (Dewetron)

  • High Speed Data Acquisition System with Monitor
  • 32x Analog ports, 8x CAN and 8x Digital port

e-DAQ

  • Data Acquisition System for Shock, Vibration, Thermal Signal
  • 4x Analog ports, 3x CAN and 1x GPS ports
  • Supports up to 7 eDAQ signal conditioning layers (except ECOM)

CompacRIO (NI)

  • Real time RT Platform
  • Small Vibration and Acoustic Measurements
  • Electromechanical Components Test System
  • High channel count, distributed sytem

RT3002 V2 (OxTS)

  • High PRecision GPS/INS System
  • X, Y, Z Acceleration : 100m/s^2
  • X, Y, Z Angular rate 100˚/sec
  • Speed Accuracy : 0.1km/h
  • Local Position Accuracy : 0.01m(RTK with DGPS)
  • Angular Accuracy : 0.05˚(roll, pitch), 0.2˚(heading)

RV4 Wheel vector sensor (Kistler)

  • wheel Vector Sensor for Vehicle
  • Wheel Vector measuring ranges X, Y axis : ±150mm, Z-axis : ±200mm
  • Measuring Toe, Camber, Caster angle
